I downloaded Teaching Tech's backplate for the BL Touch but after printing and installing I found that the X Axis limit switch was not engaging.

I went about changing the limit switch cover but with testing I had found that it was the actual plate that was not letting the limit switch get hit.

So I went about remixing the back plate so that it would always contact the switch, essentially making is a bigger surface area.

I made a new mount plate for the actual BL Touch but all it was, was taking the 45 degree supports away from Michaels original design so I have added his into here.

When printing the plate, put it up on its end so that you print the flat side first and you will have no issues. There is not issue with structural integrity as it is sandwiched between the 2 parts of the Xchange head with bolts running through it.

I have also included the X Axis gear cover that I have remixed too

I also included a remixed electronics cover for the top that needs no support material or rafts etc, just print upside down.

Print Settings

Printer Brand:

Creality

Printer:

Rafts:

No

Supports:

Resolution:

.3

Infill:

Filament: AMZ3D PLA

Category: 3D Printer Accessories
