Check out the full build video here: https://youtu.be/yerYsAh5nNQ

Designed using Sketchup Pro. All Sketchup files are available for personal modification using Sketchup.

**A few people reported that this did not fit their Ender 3, but it will fit! It's just due to many default slicer settings making the bed smaller than it should be. Many slicers will give the Ender 3 a print volume of 210x220 instead of 220x220. To fix this in PrusaSlicer you can follow these steps:

1. Go to "Printer Settings"
2. Click "Advanced" in the upper right corner
3. Select "Bed Shape", by default this will say 210 x 220mm bed size.
4. Change this to 220x220mm.

The part should now fit and be printable. For some reason many slicers use this bed size even though Creality's official print volume states 220x220.**

Don't hesitate to ask any questions if you have any.

Stuff required to build this case: (Affiliate links)
M3 by 10mm machine screws: https://amzn.to/3ngobi1
3D Printer filament (PLA or PETG): https://amzn.to/40f7T7z
Computer screw kit: https://amzn.to/3FRqXRa
Power button 12mm: https://amzn.to/3lHY9DX
3x Noctua 92x14mm fans:
Power socket with switch: https://amzn.to/42Hb8X5
Any C13 cable to connect to the socket internally in the case. (You probably have one extra laying around already)
A 3D printer: https://amzn.to/3lJtfuW

PC components used (Optional):(Affiliate links)
CPU: Intel Core i5 10400 (LGA1200): https://amzn.to/3lNh2Fp
GPU: Gigabyte 1660 Super ITX OC: https://amzn.to/3LO2uQJ
Motherboard: Asus ROG B460i (LGA1200): https://amzn.to/40iyyAD
CPU Cooler: Noctua L9i Chomax: https://amzn.to/3TLZDJK

Chassis fans: Noctua A9x14 Chromax (black edition): https://amzn.to/40yPYbY
Power supply: Any SFX size that can provide enough watts: https://amzn.to/42HigTf
2.5 inch hard drive: https://amzn.to/3LVkBnJ

Creality

CR-10

No

No

0.3 layers with 0.6 nozzle

20

No parts require support material. One external cover with corner ears for peace of mind to keep corners sticking. One version without for Ender-3 or similar printers. Adding a brim is recommended where possible for the cover. Optional on all other parts.
